40W 200-1400mA RTLD040-1400A-SA-RF Programmable Constant Current LED Driver by Enedo

STRATO EVO 40W switch mode driver technology is designed to generate one constant current output from an AC wide input voltage range. The size and performance of these products make them the ideal choice for LED lighting applications.

• Wide input voltage range: 120 – 277 VAC
• Constant current output
• IEEE 1789 Compliant (tested from 50% to 100% Imax)
• Low dimming level (down to 1 % of max current)
• IP64 package
• Low standby power consumption (<0.5 W)
• High efficiency (up to 87 %)
• Easily programmable via RFID (wireless) or wired tools
• Programmable output current settings
• Dimmable with 1-10V / 0-10V dimmers. Dim to OFF (DTO)
• Temperature sensor input (NTC) to protect the LED light engine
• Intended for convection cooling operation
• UL Class 2 output, reinforced / double isolation
• Wide operating temperature range -30 C up to 90 °C Tc
• 8-year warranty under useful life condition
• Compliance with Regulation (EU) 2019/2020 (Ecodesign)

  Note: Product has been discontinued by the manufacturer, but a replacement is available. Any orders of this product will be fulfilled with an equivalent substitute.
