ES40P-A1-15K-4MS-50-80-CL-HV-CRM-SRG-10V High Voltage Performance Line, 5000K, 15544 lm by LinmoreLED

$472.00

Essentials Series 4.0 provides the highest quality, reliability, and performance with extraordinary lumen maintenance and efficacy, delivering superior ROI for your application. Designed with best-in-class thermal management to perform at ambient temperatures up to 65°C.

  • 347-480V Input Voltage
  • Performance Line
  • -40°C up to 65°C (-40°F up to 149°F) Ambient Range Temp
  • 5000K CCT
  • 4MS Frame Linear High Bay
  • 15,544 Lumens
  • Dry/Damp Location Rated
  • Cable-ready (standard) for suspension mounting or 3/4” stem mount
  • >80 Color Rendering Index (CRI)
  • Clear Lens, Wide Distribution
  • 0-10V Dimmable Driver (100%–10%)
  • Fixture installed 10kA Surge Protector fails to ON
  • 10 Year Warranty

Brand :
LinmoreLED
Model Number :
ES40P-A1-15K-4MS-50-80-CL-HV-CRM-SRG-10V
Type :
Linear
Lumens :
15,544 lm
Watts :
94W
Voltage :
347-480V
Color Temperature :
5000K
CRI :
80+
Optics :
Wide
Mounting :
Ceiling, Pendant, Suspended
Environment :
Damp Location, Dry Location
Temperature :
Standard
Dimmable :
0-10V
Ratings :
Damp, DLC Premium, Dry
Safety Certification :
DLC Premium, ETL Listed, FCC
Dimensions (L x W x H) :
23.1" x 11.2" x 2.1"
Weight :
10
