XLC-25-H-N Multiple Stage Constant Power LED Driver by Mean Well

XLC-25 series is a 25W with constant power output LED driver. It can operate from 100-305V AC and output current ranging between 300mA to 1050mA selectable by DIP switch or NFC setting. Thanks to high efficiency up to 88%, it is able to operate for -25ºC~85ºC case temperature under free air convection. XLC-25 series is designed based on latest safety regulations with 3-in-1 and DALI-2 dimming. XLC-25 can also be adjusted for brightness with a push button as a simple way dimming, so it provides more flexibility for LED lighting application.

• Constant power mode output with multiple stage selectable by ETS database
• Plastic housing with Class II and PFC design
• Flicker-free, complying with CE ErP directive
• Standby power consumption <0.5W
• Meet emergency lighting (EL) application
• Minimum dimming level 0.1%
• 5 years warranty
