XLG-150-M-DA2 Constant Power DALI-2 LED Driver by Mean Well

XLG-150-DA2 series is a 150W LED AC/DC driver featuring the constant power mode with DALI-2 dimming function. XLG-150-DA2 operates from 100-305VAC and offers models with different rated current ranging between 700mA and 4170mA. Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for -40℃+90℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world. XLG-150-DA2 series comply with the latest version of IEC61347/GB19510.1 and UL8750 international safety regulations. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the safety of both user and luminaire system during installation.

• Wide input range 100~305V AC (Class I)
• Full power output at 70~100% constant power mode operation
• Metal case with IP67, suitable for outdoor application
• Surge protection with 6KV/4KV
• DALI-2 dimming with minimum level 8%
• 12V/250mA auxiliary power available (optional)
• India (EESL) version with input over voltage protection can survive input voltage stress of 440Vac for 48 hours
• Protection functions: SCP/OTP
• Lifetime >50,000 hours and 5 years warranty
