XLG-320-48-ABV Constant Power LED Driver by Mean Well

XLG-320 series is a 315W LED AC/DC driver featuring with constant power mode. XLG-320 operates from 120~305VAC and offers models with different rated current ranging between 1050mA and 7420mA. Thanks to the high efficiency up to 94.5% with the fan-less design, the entire series is able to operate for -40℃ ~ +85℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world. XLG-320 series comply with the latest version of IEC61347/GB19510.1 and UL8750 international safety regulations. The output and dimming circuit are also completely in accordance with the new regulations and isolation to ensure the safety of both user and luminaire system during installation.

• Wide input range 100~305VAC (class I)
• Full power output at 75~100% constant power mode operation
• Metal case with IP67, suitable for outdoor application
• Surge protection with 6KV/4KV
• 3 in 1 dimming (Dim-to-off and Isolation design)
• Protection Functions: OLP / SCP / OVP / OTP
• Compliance to EN60335-1 household application
• Lifetime >50,000 hours and 5 years warranty
