XLG-50-L-DA2 Constant Power DALI-2 LED Driver by Mean Well

XLG-50-DA2 series is a 50W AC/DC LED driver featuring the constant power mode output. XLG-50-DA2 operates from 90~305VAC. Thanks to the high efficiency up to 89%, the entire series is able to operate between -40 °C ~ +85 °C wide case temperature range with air convection. The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications. XLG-50-DA2 is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. XLG-50-DA2 series comply with the latest version of IEC61347/GB19510.1 and UL8750 international safety regulations. The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the safety of both user and luminaire system during installation.

• Constant Power mode output
• Metal housing design with functional Ground
• Built-in active PFC function
• Class 2 power unit (except for L type)
• Standby power consumption <0.5W
• IP67 rating for indoor or outdoor installations
• Surge protection with 6KV/4KV
• DALI-2 Dimming with minimum level 8%
• India (EESL) version with Input Over Voltage Protection can survive input voltage stress of 440Vac for 48 hours
• Typical lifetime >50000 hours
• 5 years warranty
