XLG-75-H-DA2 Constant Power wtih DALI-2 LED Driver by Mean Well

XLG-75-DA2 series is a 75W LED AC/DC driver featuring the constant power mode with DALI-2 dimming function . XLG-75-DA2 operates from 100~305VAC and offers models with different rated current ranging between 700mA and 2100mA . Thanks to the high efficiency up to 90 % , with the fanless design , the entire series is able to operate for - 40°C~+90°C case temperature under free air convection . The design of metal housing and IP67 ingress protection level allows this series to fit both indoor and outdoor applications . Moreover the innovative environment-adaptive capability allows this series to reliably light on the LEDs for all kinds of application environments in almost any spots that may install LED luminaires in the world . XLG-75-DA2 series comply with the latest version of IEC61347/GB19510.1 and UL8750 international safety regulations . The output and dimming circuit are also completely in accordance with the new regulations with isolation to ensure the safety of both user and luminaire system during installation .

• Wide input range 100~305V AC(Class I )
• Full power output at 70~100 % Constant power mode operation
• Metal case with IP67 , suitable for outdoor application
• Class 2 power unit ( except for L type )
• Surge protection with 6KV/4KV
• DALI-2 Dimming with minimum level 8 %
• India ( EESL ) version with Input Over Voltage Protection can survive input voltage stress of 440Vac for 48 hours
• Protection functions : SCP/OTP
• Life time > 50,000 hrs . and 5 years warranty
