XLN-40-H Multiple Stage Constant Power LED Driver by Mean Well

XLN-40 Series is a 40W with constant power and constant voltage output LED driver . It can operate from 100~305VAC and output current ranging between 600 mA to 1400 mA selectable by NFC setting . Thanks to high efficiency up to 88 % , it is able to operate for - 25°C~90°C case temperature under free air convection . XLN-40 is designed based on latest safety regulation with 3 in 1 and DALI-2 dimming . XLN-40 can also be adjusted for brightness with a push button as a simple way dimming , so it provides more flexibility for LED Lighting application.

• Constant power mode output with multiple stage selectable by NFC setting (H-type)
• Constant voltage mode output(12V/24V )
• Plastic housing with class II and PFC design
• Meet UL 8750 Class 2 / Class P power unit
• Flicker free , complying with CE ErP directive
• Standby power consumption < 0.5W
• Meet emergency lighting ( EL ) function application
• Fully encapsulated with IP67
• Minimum dimming level 0.1 % ( DALI-2 DT6 )
• Dimming functions : 3 in 1 dimming (Dim-to-off )
• DALI-2 + Push dimming
• 5 years warranty
