XLN-60-H Multiple Stage Constant Power LED Driver by Mean Well

XLN-60 Series is a 60W with constant power and constant voltage output LED driver. It can operate from 100~305VAC and output current ranging between 900 mA to 1700 mA selectable by NFC setting. Thanks to high efficiency up to 90 %, it is able to operate for - 25°C~90°C case temperature under free air convection. XLN-60 is designed based on latest safety regulation with 3 in 1 and DALI-2 dimming. XLN-60 can be adjusted for brightness with a push button as a simple way dimming, so it provides more flexibility for LED Lighting application.

• Constant power mode output with multiple stage selectable by NFC setting (H-type)
• Constant voltage mode output available (12/24/48V)
• Plastic housing with class II and PFC design
• Meet UL8750 Class 2 / Class P power unit
• Flicker free, complying with CE ErP directive
• Standby power consumption < 0.5W
• Meet emergency lighting (EL) application
• Fully encapsulated with IP67
• Minimum dimming level 0.1 % (DALI-2 DT6)
• Dimming functions: 3 in 1 dimming (Dim-to-off) DALI-2 + Push dimming
• 5 years warranty
