4' x 4" Power + CCT Selectable JADLR Recessed Architectural Linear by Jademar
$210.00
Construction and Materials
- Extruded aluminum housing
- Ultra-Thin Profile 0.59” (15mm)
Optical System
- Light Distribution: 120°
Electrical System
- Power: 40W/30W/20W (4` Models) and 80W (8` Models)
- Input Voltage: 120-277VAC
- Efficacy: 138 lm/W
- Power Factor: >0.9
- CRI: >80
- Operating Temp: -40°F to 113°F (-40°C to 45°C)
- Total Harmonic Distortion: <15%
- Integral Surge Protection: 6kV Surge Protection Standard
Dimming and Controls
- 0-10V Dimming Standard
Certifications and Compliance
- UL Listed
- Ingress Protection: IP66 for Wet Locations
- RoHS Compliant
- Meets FCC Part 15, Subpart B, Class A limits for conducted and radiated Emissions
- Lifetime Based on TM21
- L70 ≥ 150,000 / L80 ≥ 120,000 / L90 ≥ 61,000 Hrs
- Warranty: 10 Years
- TG 4 26 N G1 35K F - 4' 20W T-Grid Linear Light, G1 Fineline Ceiling, 3500K, White Finish by SLG
- TG 4 26 W G1 35K F - 4' 20W T-Grid Linear Light, G1 Standard Ceiling, 3500K, White Finish by SLG
- TG 4 26 N G1 40K F - 4' 20W T-Grid Linear Light, G1 Fineline Ceiling, 4000K, White Finish by SLG
Brand :
Jademar
Model Number :
JADLR-44-40W-CPS-D
Type :
T-Bar
Mounting :
Recessed, T-Bar
Lumens :
Selectable 1,680 - 3,513 lm
Watts :
Selectable 20W/30W/40W
Color Temperature :
Selectable, 3000K, 3500K, 4000K
CRI :
80+
Dimming Type :
0-10V
Dimming Range :
Not Available
Voltage :
120-277V
Optics :
120°
Distribution :
Direct
Housing Color :
White
Ratings :
IP66, Wet Location
Safety Certification :
FCC, UL Listed
Dimensions (L x W x H) :
47.76" x 3.74" x 2.17"
