EN-ALC-1R10V-GB2-BK Area Lighting Controller, 0-10V Dimming, Black Finish by Wattstopper

The Area Lighting Controller (ALC) provides a high-power switching and dimming interface between a group of luminaires and the GreenBus™ communication network. Individually addressable with the Wattstopper PLUS Lighting Control System, the ALC switches a single wired zone of multiple luminaires ON or OFF via an integral high current relay while setting the zone's overall light level with a 0-10V dimming output wired to the luminaires' dimming ballasts or LED drivers. The ALC's dimming output is fully isolated and suitable for installation as either an NEC Class 2 or Class 1 circuit. The ALC can switch an entire circuit of electrical loads and is suitable for general purpose plug load control. It replaces the need for standard power relays or switch packs and is Damp Rated.
